Product Details
- Size: 83
- Place of Origin: china
- Brand Name: hecha
- Model Number: HECHA300
- Weight: 7.000 kg
| Performance parameters | ||||||
| 1 | Model | HECHA300 | HECHA360 | HECHA400 | ||
| 2 | Weight(set) | Kg | 7 | 7.5 | 8 | |
| 3 | Rated lifting weight | Kg | 15000 | 18000 | 20000 | |
| 4 | The maximum speed (no load) | Km/h | 3.5 | 3.5 | 3.5 | |
| 5 | The minimum channel width | mm | 3200 | 3200 | 3200 | |
| 6 | Rated torque hydraulic motor | Nm | 1010 | 1010 | 1010 | |
| 7 | Maximum lifting speed | Load | mm/s | 30 | 30 | 30 |
| 8 | No load | mm/s | 35 | 35 | 35 | |
| 9 | The maximum lowering speed | Load | mm/s | 25 | 25 | 30 |
| 10 | No load | mm/s | 25 | 25 | 25 | |
| 11 | Engine power | Kw | 22 | 22 | 22 | |
| 12 | The system pressure | Mpa | 13 | 15 | 16 | |
| 13 | The steering wheel rotation angle | º | 110 | 110 | 110 | |
| Structure parameters | ||||||
| 14 | Length * width * height | mm | 5055*2655*6320 | |||
| 15 | Crane beam maximum height | mm | 4460 | 4460 | 4460 | |
| 16 | Hoisting beam of the minimum height from the ground | mm | 2270 | 2270 | 2270 | |
| 17 | The minimum ground clearance | mm | 110 | 110 | 110 | |
| 18 | Longitudinal track | mm | 2205 | 2205 | 2205 | |
| 19 | The transverse track | mm | 3725 | 3725 | 3725 | |
| 20 | The horizontal width | mm | 3275/3380 | 3275/3380 | 3275/3380 | |
